@nomideusz/svelte-geometrize

Geometric image placeholders for Svelte 5 — instead of a blur, triangles resolve into the photo while it loads, geometrize.co.uk-style.

Live demo → svelte-geometrize.vercel.app · In production on szkolyjogi.pl, where 700+ listing heroes paint an instant geometric preview of the photo while it loads (open any school page, e.g. this one — hard-refresh to replay), and on kurcz.pl.

The expensive shape fitting (hill-climbing, via geometrizejs) runs at build time and emits a small ordered shape list (~1–3 KB raw, far less gzipped). Because geometrize is iterative — shape 1 is the dominant region, shape 100 is fine detail — replaying the shapes in fit order makes the placeholder visibly sharpen until the real image takes over, cut into the same shapes. The runtime component is tiny and dependency-free (sharp is an optional peer for the Node / Vite / CLI half only).

Install

pnpm add @nomideusz/svelte-geometrize
# only needed for the Vite plugin, Node API, or CLI:
pnpm add -D sharp

Usage

Register the Vite plugin (build-time half):

// vite.config.ts
import { geometrize } from '@nomideusz/svelte-geometrize/vite';

export default defineConfig({
	plugins: [geometrize(), sveltekit()]
});

Then in a component:

<script lang="ts">
	import { GeometrizedImage } from '@nomideusz/svelte-geometrize';
	import placeholder from './photo.jpg?geometrize';
	import src from './photo.jpg';
</script>

<GeometrizedImage {placeholder} {src} alt="Sunset over mountains" revealMs={850} loading="lazy" />

For typed ?geometrize imports, either copy the declarations into app.d.ts or reference the shipped ambient types:

/// <reference types="@nomideusz/svelte-geometrize/client" />

Options

Plugin-wide defaults via geometrize({ ... }), per-image overrides via query params:

./photo.jpg?shapes=150&alpha=160&maxSize=160&shapeTypes=triangle,ellipse&seed=1&geometrize

Param order doesn't matter to the plugin, but keeping geometrize last lets the *&geometrize module declaration type these imports.

A preset is a named look — its shape types and opacity — for when you'd rather pick one than tune two knobs:

./photo.jpg?preset=soft&geometrize

A preset named on the import beats the plugin-wide shapeTypes / alpha; set either on the import itself and yours wins. PRESETS is exported from every entry.

Fits are cached on disk by file content hash + resolved options, so clean rebuilds skip already-fitted images. Concurrent loads of the same key coalesce.

Component props beyond placeholder / src / alt: reveal ('fade' | 'pop' | 'scatter', default 'fade'), revealMs (total ms until the last shape starts — preferred over raw stagger), stagger (ms between shapes, default 15), shapeDuration (per-shape fade, default 400), fadeDuration (the handoff, default 1300: the photo opens through the shapes, smallest first, slowing as the big ones open, then fills the gaps between them — no crossfade, no blur), objectFit (cover | contain | fill | …, default cover), objectPosition (default center; keywords, percentages or lengths, not var()) — the placeholder crops exactly like the photo, so a box that isn't the photo's shape hands off without a jump. onload / onerror are forwarded (chained after the internal reveal). All other props go to the <img>. Width/height default from the placeholder. The reveal is pure CSS, plays with SSR before hydration, and respects prefers-reduced-motion; a photo that is ready before it has played waits for the last shape to start, so a fast load still shows the picture sharpening.

Node API

import {
	generatePlaceholder,
	generatePlaceholderFromUrl,
	placeholderToSvg,
	placeholderToDataUri
} from '@nomideusz/svelte-geometrize/node';

const placeholder = await generatePlaceholder('photo.jpg', { shapes: 80, seed: 1 });
const fromCms = await generatePlaceholderFromUrl('https://cdn.example/hero.jpg');
const svg = placeholderToSvg(placeholder);

Requires the optional peer sharp.

Browser / worker fitter

import { fitShapes } from '@nomideusz/svelte-geometrize/fit';

// rgba from canvas getImageData / a worker — no sharp
const placeholder = fitShapes(rgba, width, height, sourceW, sourceH, { shapes: 60 });

placeholderToSvg / placeholderToDataUri are also exported from the root entry (no geometrize/sharp) for CSS backgrounds or og-images.

CLI

npx svelte-geometrize photo.jpg -o photo.json
npx svelte-geometrize ./photos --out ./placeholders --shapes 80 --target-score 0.12
npx svelte-geometrize hero.jpg --preset soft

Dynamic images (runtime srcs, DB-stored placeholders)

The Vite plugin covers images known at build time. For photos that live behind an API — CMS content, user uploads, scraped listings — generate the placeholder once at ingest (or in a backfill script) with the Node API / CLI, store the JSON next to the record, and pass it straight to the component. This is how szkolyjogi.pl does its listing heroes:

import { generatePlaceholder } from '@nomideusz/svelte-geometrize/node';

const bytes = Buffer.from(await (await fetch(photoUrl)).arrayBuffer());
const placeholder = await generatePlaceholder(bytes);
await db.update(listings)
	.set({ photoPlaceholder: JSON.stringify(placeholder) })
	.where(eq(listings.id, id));

<GeometrizedImage
	placeholder={listing.photoPlaceholder}
	src="/api/photo/{listing.id}"
	alt={listing.name}
	revealMs={900}
/>

A placeholder is numbers, not markup: 30 shapes ≈ 800 B raw, 100 ≈ 2.5 KB (a fraction of that gzipped), so inlining it in server-rendered HTML is cheap even for a gallery — the geometric preview paints before the photo's first byte arrives, no layout shift, and sharp stays a server-side ingest dependency, never shipped to the client.

The placeholder format

{ "v": 2, "w": 1600, "h": 1067, "fw": 128, "fh": 85, "bg": "#695346", "a": 0.502,
  "s": "p25,0,24,49,0,37,f29157;p0,12,15,49,0,41,ff9402;…" }

s lists the shapes in fit order, ;-separated: a kind letter, integer parameters in the fw × fh space, and a 6-hex colour (p polygon, r/R rectangle / rotated, e/E ellipse / rotated, c circle, l line, q quadratic bézier). a is the shared opacity. Helpers for stored placeholders, all browser-safe:

• shapeCount(p) — how many shapes it holds.
• takeShapes(p, n) — the first n shapes: a coarser preview for less bytes, no re-fit (the fit is ordered, so the big regions come first). Store 100, send 30 on a list page and 100 on the detail page.
• compactPlaceholder(p) — re-encodes a pre-0.7 placeholder (one SVG string per shape, about 3× the bytes) in this format, for a one-off migration of what you already have stored. Everything still accepts the old format as-is.

Demo

pnpm install
pnpm dev
